Arista 7280R, 24x40GbE QSFP+ & 12x100GbE QSFP switch, rear to front air, 2x AC and 2xC13-C14 cords
Deskripsi
SPESIFICATION
| Model Comparison | 7280QR-C36 E |
| Ports | 36 x QSFP |
| (24x QSFP+ and | |
| 12x QSFP100) | |
| Max 100GbE Ports | 12 |
| Max 50GbE Ports | 24 |
| Max 40GbE Ports | 36 |
| Max 25GbE Ports | 48 |
| Max 10GbE Ports | 144 |
| Throughput (fd) | 4.32 Tbps |
| Packets/Second | 1.44 Bpps |
| Latency | From 3.8 us |
| CPU | Quad-Core x86 |
| System Memory | 8 GB (32 GB optional) |
| Packet Buffer Memory | 8 GB |
| USB Ports | 1 |
| Flash Storage Memory | 4 GB |
| SSD Storage Option | Yes |
| 100/1000 Mgmt Ports | 1 |
| RS-232 Serial Ports | 1 (RJ-45) |
| Hot-swap Power Supplies | 2 (1+1 redundant) |
| Hot-swappable Fans | 4 (N+1 redundant) |
| Reversible Airflow Option | Yes |
| Rack Units | 1 U |
| Size (WxHxD) | 19 x 1.75 x 20.6” |
| (48.3 x 4.4 x 52.3cm) | |
| Typical/Max Power Draw 1 | 324W / 499W |
| Weight | 21lbs (9.7kg) |
| NEBS | Yes |
| Fan Tray | FAN-7000-F/R |
| Power Supplies | 745W AC |
| 1900W DC | |
| AlgoMatch | No |
| Accelerated sFlow | No |
| EOS Feature Licenses | Group 2 |
| Minimum EOS | 4.17.1 |
